Find C/C++ memory leak with valgrind on Linux
Install valgrind
sudo apt install valgrind # Ubuntu, Debian, etc.
sudo yum install valgrind # RHEL, CentOS, Fedora, etc.
Find memory leak
#include <stdlib.h>
int main()
{
int *array = malloc(sizeof(int));
return 0;
}
gcc -g -o memory-leak memory-leak.c
valgrind --tool=memcheck --leak-check=full ./memory-leak
==43199== Memcheck, a memory error detector
==43199== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==43199== Using Valgrind-3.16.1 and LibVEX; rerun with -h for copyright info
==43199== Command: ./memory-leak
==43199==
==43199==
==43199== HEAP SUMMARY:
==43199== in use at exit: 4 bytes in 1 blocks
==43199== total heap usage: 1 allocs, 0 frees, 4 bytes allocated
==43199==
==43199== 4 bytes in 1 blocks are definitely lost in loss record 1 of 1
==43199== at 0x483877F: malloc (vg_replace_malloc.c:307)
==43199== by 0x109146: main (m-l.c:4)
==43199==
==43199== LEAK SUMMARY:
==43199== definitely lost: 4 bytes in 1 blocks
==43199== indirectly lost: 0 bytes in 0 blocks
==43199== possibly lost: 0 bytes in 0 blocks
==43199== still reachable: 0 bytes in 0 blocks
==43199== suppressed: 0 bytes in 0 blocks
==43199==
==43199== For lists of detected and suppressed errors, rerun with: -s
==43199== ERROR SUMMARY: 1 errors from 1 contexts (suppressed: 0 from 0)
Find illegal read write
#include <stdlib.h>
int main()
{
int *ptr=0;
(*ptr)=33;
return 0;
}
==43241== Memcheck, a memory error detector
==43241== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==43241== Using Valgrind-3.16.1 and LibVEX; rerun with -h for copyright info
==43241== Command: ./memory-leak
==43241==
==43241== Invalid write of size 4
==43241== at 0x109135: main (m-l.c:5)
==43241== Address 0x0 is not stack'd, malloc'd or (recently) free'd
==43241==
==43241==
==43241== Process terminating with default action of signal 11 (SIGSEGV)
==43241== Access not within mapped region at address 0x0
==43241== at 0x109135: main (m-l.c:5)
==43241== If you believe this happened as a result of a stack
==43241== overflow in your program's main thread (unlikely but
==43241== possible), you can try to increase the size of the
==43241== main thread stack using the --main-stacksize= flag.
==43241== The main thread stack size used in this run was 8388608.
==43241==
==43241== HEAP SUMMARY:
==43241== in use at exit: 0 bytes in 0 blocks
==43241== total heap usage: 0 allocs, 0 frees, 0 bytes allocated
==43241==
==43241== All heap blocks were freed -- no leaks are possible
==43241==
==43241== For lists of detected and suppressed errors, rerun with: -s
==43241== ERROR SUMMARY: 1 errors from 1 contexts (suppressed: 0 from 0)
Segmentation fault
Find invalid pointer
#include <stdlib.h>
int main()
{
char *x = malloc(10);
x[10] = 'a';
return 0;
}
==43275== Memcheck, a memory error detector
==43275== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==43275== Using Valgrind-3.16.1 and LibVEX; rerun with -h for copyright info
==43275== Command: ./memory-leak
==43275==
==43275== Invalid write of size 1
==43275== at 0x109153: main (m-l.c:6)
==43275== Address 0x4a1604a is 0 bytes after a block of size 10 alloc'd
==43275== at 0x483877F: malloc (vg_replace_malloc.c:307)
==43275== by 0x109146: main (m-l.c:5)
==43275==
==43275==
==43275== HEAP SUMMARY:
==43275== in use at exit: 10 bytes in 1 blocks
==43275== total heap usage: 1 allocs, 0 frees, 10 bytes allocated
==43275==
==43275== 10 bytes in 1 blocks are definitely lost in loss record 1 of 1
==43275== at 0x483877F: malloc (vg_replace_malloc.c:307)
==43275== by 0x109146: main (m-l.c:5)
==43275==
==43275== LEAK SUMMARY:
==43275== definitely lost: 10 bytes in 1 blocks
==43275== indirectly lost: 0 bytes in 0 blocks
==43275== possibly lost: 0 bytes in 0 blocks
==43275== still reachable: 0 bytes in 0 blocks
==43275== suppressed: 0 bytes in 0 blocks
==43275==
==43275== For lists of detected and suppressed errors, rerun with: -s
==43275== ERROR SUMMARY: 2 errors from 2 contexts (suppressed: 0 from 0)
Find uninitialised variables
#include <stdlib.h>
#include <stdio.h>
int main()
{
int number; //Should be initialized (i.e. to zero).
if (number==0)
{
printf("number is zero");
}
return 0;
}
==43304== Memcheck, a memory error detector
==43304== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==43304== Using Valgrind-3.16.1 and LibVEX; rerun with -h for copyright info
==43304== Command: ./memory-leak
==43304==
==43304== Conditional jump or move depends on uninitialised value(s)
==43304== at 0x109141: main (m-l.c:6)
==43304==
number is zero==43304==
==43304== HEAP SUMMARY:
==43304== in use at exit: 0 bytes in 0 blocks
==43304== total heap usage: 1 allocs, 1 frees, 1,024 bytes allocated
==43304==
==43304== All heap blocks were freed -- no leaks are possible
==43304==
==43304== Use --track-origins=yes to see where uninitialised values come from
==43304== For lists of detected and suppressed errors, rerun with: -s
==43304== ERROR SUMMARY: 1 errors from 1 contexts (suppressed: 0 from 0)
Find illegal memory frees
#include <stdlib.h>
#include <stdio.h>
int main()
{
int * ptr=malloc(4);
free(ptr);
ptr++; //To mismatch
free(ptr);
return 0;
}
==43329== Memcheck, a memory error detector
==43329== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==43329== Using Valgrind-3.16.1 and LibVEX; rerun with -h for copyright info
==43329== Command: ./memory-leak
==43329==
==43329== Invalid free() / delete / delete[] / realloc()
==43329== at 0x48399AB: free (vg_replace_malloc.c:538)
==43329== by 0x109177: main (m-l.c:8)
==43329== Address 0x4a16044 is 0 bytes after a block of size 4 free'd
==43329== at 0x48399AB: free (vg_replace_malloc.c:538)
==43329== by 0x109166: main (m-l.c:6)
==43329== Block was alloc'd at
==43329== at 0x483877F: malloc (vg_replace_malloc.c:307)
==43329== by 0x109156: main (m-l.c:5)
==43329==
==43329==
==43329== HEAP SUMMARY:
==43329== in use at exit: 0 bytes in 0 blocks
==43329== total heap usage: 1 allocs, 2 frees, 4 bytes allocated
==43329==
==43329== All heap blocks were freed -- no leaks are possible
==43329==
==43329== For lists of detected and suppressed errors, rerun with: -s
==43329== ERROR SUMMARY: 1 errors from 1 contexts (suppressed: 0 from 0)
Reference
http://www.it.uc3m.es/pbasanta/asng/course_notes/memory_profiler_en.html#memcheck_tool
https://www.cprogramming.com/debugging/valgrind.html
